'Owl' IP65 Maxim GMSL 2 2.3MP Imaging Camera
A$0.00
In stock
SKU
LI-AR0234CS-GMSL2-OWL
IP65 Maxim GMSL 2 Camera
Key Features:
ON Semiconductor CMOS Image Sensor AR0234CS Color Sensor GMSL2 Serializer GMSL2 Serial Coax Interface with PoC Certification FCC, CE Lens: FOV H 202.0°± 3° Active Pixel: 1920 (H) x 1200 (V) Frame Rate: 120 fps @ full resolution Pixel Size: 3.0 x 3.0 μm Power Supply Range: 9 ~ 19 VDC Focusing Distance: 50cm (lens is glued)
The LI-AR0234CS-GMSL2-OWL is equipped with ON Semiconductor CMOS 2.3MP digital image sensor AR0234CS, capable of producing clear, low-noise images in both low-light and bright scenes. This camera outputs 1920 x 1200 RAW data.
More Information
brand
Leopard Imaging
Specifications
General
Sensor
ON Semiconductor CMOS 2.3MP Image Sensor AR0234CS
Optical Format
1/2.6"
Resolution
1920 (H) x 1200 (V) (active pixels)
Pixel Size
3.0 x 3.0 μm
Output Format
10-bit RAW
Color / Mono
Color sensor
Frame Rate
120 fps @ full resolution
Shutter
Global shutter
Serializer
Maxim MAX9295A/B
Power Supply Range
9 ~ 19 VDC
IP Rating
IP65
FAKRA Connector
FAKRA Z TYPE
Power Consumption
70 mA @ 12 VDC
Operating Temp
-20℃ ~ +50℃
Storage Temp
-20℃ ~ +50℃
Weight
~ 37 g
Part#
LI-AR0234CS-GMSL2-OWL
Certifications
FCC, CE
Lens
Focal Length
1.34 ± 5%
Aperture, F/#
2.0 ± 5%
Field of View (FOV)
202.0˚ ± 3˚ horizontal
127.2˚ ± 2˚ vertical
IR Filter
650 nm ± 10 nm IR cut filter
Lens Mount
M12 x 0.5
Description
The LI-AR0234CS-GMSL2-OWL is equipped with ON Semiconductor CMOS 2.3MP digital image sensor AR0234CS, capable of producing clear, low-noise images in both low-light and bright scenes. This camera outputs 1920 x 1200 RAW data.
