OPS700-520, 8th gen LGA1151 i series CPU, Intel Q370

A$0.00

In stock

SKU

OPS700-520

Open Pluggable Specification-Plus (OPS+) Digital Signage Player with LGA1151 Socket 8th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor, Intel® Q370 and TPM 2.0

Details

Open Pluggable Specification-Plus (OPS+) Digital Signage Player with LGA1151 Socket 8th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor, Intel® Q370 and TPM 2.0

· Intel® Open Pluggable Specification-Plus (OPS+ compliance)

· 8th gen Intel® Core™ i7/i5/i3 & Celeron® processors (Coffee Lake-S)

· 2 DDR4-2400 SO-DIMM for up to 32GB of memory

· 1 M.2 Key M for SATA storage

· 1 M.2 Key E for Wi-Fi solution

· Supports additional DisplayPort and PCIe x4 through HRS-FX18 connector

· Supports Intel® AMT 11.0 and Intel® Unite

· Supports Trusted Platform Module (TPM) 2.0

· Easy installation and maintenance

More Information

brand

Axiomtek

Specifications

CPU	LGA1151 socket 8th gen Intel® Core™ i7/i5/i3 & Celeron® processor, 35W TDP
Chipset	Intel® Q370
System Memory	2 x 260-pin SO-DIMM DDR4-2400, up to 32GB
BIOS	AMI
COM	1 x RS-232
USB	2 x USB 2.0 2 x USB 3.1 Gen2 Type A
Ethernet	1 x 10/100/1000 Mbps (Intel® i219-LM)
Display	1 x HDMI with 4K/Full HD resolution (Default: Full HD)
Audio	N/A
JAE Connector	1 x DisplayPort with 4K 60Hz supported 1 x HDMI 2.0 with 4K 60Hz supported 2 x USB 2.0 1 x USB 3.0 1 x Audio (Line-out) 1 x UART (TX/RX)
HRS Connector	1 x DisplayPort with 4K 60Hz supported 1 x PCI Express x4
Wi-Fi	802.11 b/g/n (optional)
Storage	1 x M.2 Key M for SATA storage
Expansion	1 x M.2 Key E 2230 for Wi-Fi
Power Supply	1 x 12 VDC power input (adapter available by option)
Watchdog Timer	255 levels, 1 to 255 sec.
Operating Temperature	0°C to +45°C (+32°F to +113°F) (with airflow 1.2m/s)
Dimensions (W x D x H)	200 x 119 x 30 mm (7.87” x 4.68” x 1.18”)
Weight (net/gross)	1 kg (2.21lb)/1.5 kg (3.3 lb)
Certifications	CE, FCC Class A

Description

Open Pluggable Specification-Plus (OPS+) Digital Signage Player with LGA1151 Socket 8th Gen Intel® Core™ i7/i5/i3 & Celeron® Processor, Intel® Q370 and TPM 2.0

· Intel® Open Pluggable Specification-Plus (OPS+ compliance)

· 8th gen Intel® Core™ i7/i5/i3 & Celeron® processors (Coffee Lake-S)

· 2 DDR4-2400 SO-DIMM for up to 32GB of memory

· 1 M.2 Key M for SATA storage

· 1 M.2 Key E for Wi-Fi solution

· Supports additional DisplayPort and PCIe x4 through HRS-FX18 connector

· Supports Intel® AMT 11.0 and Intel® Unite

· Supports Trusted Platform Module (TPM) 2.0

· Easy installation and maintenance
