IEC-0101FT

A$0.00

In stock

SKU

IEC-0101FT

- UL Class I Division II for Group A,B,C and D hazardous location
- Built-in LLF & LFP technology
- Wide-range redundant power with polarity reverse protection

Details

_Standards	_{IEEE 802.3 10Base-T Ethernet} _{IEEE 802.3u 100Base-TX and 100Base-FX Fast Ethernet} _{IEEE802.3x Flow Control and Back Pressure}
_Protocol	_CSMA/CD
_{Transfer Rate}	_{14,880pps for Ethernet port} _{148,800pps for Fast Ethernet port}
_Connectors	_{SC/ST (Multi-mode): 50/125um~62.5/125um} _{SC/ST (Single-mode): 9/125um} _{Available distance: 2km (Multi-mode) / 30km(Single-mode)} _{Wavelength: 1310nm (Multi-mode/Single-mode)} _{10/100TX: 1 x RJ-45 with auto MDI/MDI-X function} _{[Multi-Mode] power budget: Min: 9dB, MAX: 19dB.} _{[Single-Mode] power budget: Min: 19dB, MAX: 26dB.}
_{Transfer packet size}	_{64bytes to 1522 bytes (with VLAN tag).}
_{Mac Address}	_{2K MAC address table}
_{Network Cable}	_{10Base-T: 2-pair UTP/STP Cat. 3, 4, 5, 6 cable} _{EIA/TIA-568 100-ohm (100m)} _{100Base-TX: 2-pair UTP/STP Cat. 5, 6 cable} _{EIA/TIA-568 100-ohm (100m)}
_{DIP Switch}	_{DIP Switch 1: OFF: Disables Port /Power Alarm; ON: Enables Port /Power Alarm} _{DIP Switch 2: OFF: Disables LLF (Link Lose Forwarding) & LFP (Link Fault Pass-Through) ; ON: Enables LLF & LFP} _{DIP Switch 3: OFF: 100Base-FX Full-mode; ON: 100Base-FX Half-mode} _{DIP Switch 4: OFF: Switching mode; ON: Media mode (100TX to 100FX)}
_{Power Consumption}	_{2.74 Watts}
_{Reserve polarity protection}	_Present
_{Overload current protection}	_Present
_LED	_{Per unit: Power 1 (Green), Power 2 (Green), Fault(Red)} _{TX: Link/Active (Green), 100M(Yellow)} _{Fiber: Link/Active (Green), Full duplex/Collision (Yellow)}
_{Operating Humidity}	_{5% ~ 95% (Non-condensing)}
_{Operating Temperature}	_{-20°C~60°C / -4°F~140°F (Standard model)} _{-40°C~75°C / -40°F~167°F (-E / DNV model)}
_{Storage Temperature}	_{-40°C~85°C / -40°F~185°F}
_{Case Dimension}	_{Metal case,IP-30; 30mm(W)x95mm(D)x140mm(H)}
_Weight	_{600 g}
_{EMI & EMS}	_{FCC Class A,} _{CE EN61000-4-2 (ESD),} _{CE EN61000-4-3 (RS),} _{CE EN61000-4-4 (EFT),} _{CE EN61000-4-5 (Surge),} _{CE EN61000-4-6 (CS),} _{CE EN61000-4-8,} _{CE EN61000-4-11,} _{CE EN61000-4-12,} _{CE EN61000-6-2,} _{CE EN61000-6-4}
_Safety	_{UL, cUL, CE/EN60950} _{UL Class I Division II for Group A,B,C and D hazardous location}
_{Stability Testing}	_{IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), IEC60068-2-6 (Vibration)}
_MTBF	_{405486 hrs}
_{Power Supply}	_{24VDC (9~48VDC),12~36VAC*, Redundant power with polarity reverse protect function and removable terminal block}
_Warranty	_{5 years}

More Information

Description

_Standards	_{IEEE 802.3 10Base-T Ethernet} _{IEEE 802.3u 100Base-TX and 100Base-FX Fast Ethernet} _{IEEE802.3x Flow Control and Back Pressure}
_Protocol	_CSMA/CD
_{Transfer Rate}	_{14,880pps for Ethernet port} _{148,800pps for Fast Ethernet port}
_Connectors	_{SC/ST (Multi-mode): 50/125um~62.5/125um} _{SC/ST (Single-mode): 9/125um} _{Available distance: 2km (Multi-mode) / 30km(Single-mode)} _{Wavelength: 1310nm (Multi-mode/Single-mode)} _{10/100TX: 1 x RJ-45 with auto MDI/MDI-X function} _{[Multi-Mode] power budget: Min: 9dB, MAX: 19dB.} _{[Single-Mode] power budget: Min: 19dB, MAX: 26dB.}
_{Transfer packet size}	_{64bytes to 1522 bytes (with VLAN tag).}
_{Mac Address}	_{2K MAC address table}
_{Network Cable}	_{10Base-T: 2-pair UTP/STP Cat. 3, 4, 5, 6 cable} _{EIA/TIA-568 100-ohm (100m)} _{100Base-TX: 2-pair UTP/STP Cat. 5, 6 cable} _{EIA/TIA-568 100-ohm (100m)}
_{DIP Switch}	_{DIP Switch 1: OFF: Disables Port /Power Alarm; ON: Enables Port /Power Alarm} _{DIP Switch 2: OFF: Disables LLF (Link Lose Forwarding) & LFP (Link Fault Pass-Through) ; ON: Enables LLF & LFP} _{DIP Switch 3: OFF: 100Base-FX Full-mode; ON: 100Base-FX Half-mode} _{DIP Switch 4: OFF: Switching mode; ON: Media mode (100TX to 100FX)}
_{Power Consumption}	_{2.74 Watts}
_{Reserve polarity protection}	_Present
_{Overload current protection}	_Present
_LED	_{Per unit: Power 1 (Green), Power 2 (Green), Fault(Red)} _{TX: Link/Active (Green), 100M(Yellow)} _{Fiber: Link/Active (Green), Full duplex/Collision (Yellow)}
_{Operating Humidity}	_{5% ~ 95% (Non-condensing)}
_{Operating Temperature}	_{-20°C~60°C / -4°F~140°F (Standard model)} _{-40°C~75°C / -40°F~167°F (-E / DNV model)}
_{Storage Temperature}	_{-40°C~85°C / -40°F~185°F}
_{Case Dimension}	_{Metal case,IP-30; 30mm(W)x95mm(D)x140mm(H)}
_Weight	_{600 g}
_{EMI & EMS}	_{FCC Class A,} _{CE EN61000-4-2 (ESD),} _{CE EN61000-4-3 (RS),} _{CE EN61000-4-4 (EFT),} _{CE EN61000-4-5 (Surge),} _{CE EN61000-4-6 (CS),} _{CE EN61000-4-8,} _{CE EN61000-4-11,} _{CE EN61000-4-12,} _{CE EN61000-6-2,} _{CE EN61000-6-4}
_Safety	_{UL, cUL, CE/EN60950} _{UL Class I Division II for Group A,B,C and D hazardous location}
_{Stability Testing}	_{IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), IEC60068-2-6 (Vibration)}
_MTBF	_{405486 hrs}
_{Power Supply}	_{24VDC (9~48VDC),12~36VAC*, Redundant power with polarity reverse protect function and removable terminal block}
_Warranty	_{5 years}
