eBOX560-512-FL Fanless Embedded System
Fanless Embedded System with Intel Core i5-7300U & Celeron 3965U, 2 HDMI, 2 GbE LANs, 4 USB 3.0 and PCI Express Mini Card Slot
Key Features:
- Intel Core i5-7300U 2.6 GHz/i3-7100U 2.4 GHz & Celeron 3965U 2.2 GHz
- Supports 2 COM, 2 GbE LAN, and 4 USB 3.0
- One swappable 2.5" HDD drive bay
- 2 HDMI with dual-view supported
- AMS.AXView intelligent remote monitoring software for IIoT
- Ultra-compact enclosure design
- Trusted Platform Module 1.2 (TPM 1.2)
Fanless Embedded System with Intel® Core™ i5-7300U & Celeron® 3965U, 2 HDMI, 2 GbE LANs, 4 USB 3.0 and PCI Express Mini Card Slot
● Intel® Core™ i5-7300U 3.5 GHz & Celeron® 3965U 2.2 GHz
● Supports 2 COM, 2 GbE LAN and 4 USB 3.0
● One swappable 2.5" HDD drive bay
● 2 HDMI with dual-view supported
● AXView 2.0 intelligent remote monitoring software for IIoT
● Ultra-compact enclosure design
● Trusted Platform Module 1.2 (TPM) 1.2
More Information
| Brand |
Axiomtek |
| Specifications |
|
Standard Color
|
Silver
|
|
Construction
|
Aluminum extrusion and heavy-duty steel, IP40
|
|
CPU
|
Intel® Core™ i5-7300U 3.5 GHz
Celeron® 3965U 2.2 GHz
|
|
System Memory
|
1 x 260-pin DDR4-2133 SO-DIMM, up to 16GB
|
|
Chipset
|
SoC integrated
|
|
BIOS
|
AMI UEFI BIOS
|
|
System I/O Outlet
|
2 x RS-232/422/485
2 x HDMI
2 x 10/100/1000 Mbps Ethernet (Intel® i210-AT, i219-LM)
4 x USB 3.0
2 x SMA-type antenna connector
1 x AT/ATX quick switch
1 x ATX power switch
1 x Reset button
1 x Screw type VDC power input connector
|
|
Watchdog Timer
|
255 levels, 1 to 255 sec.
|
|
Storage
|
1 x 2.5” SATA HDD drive bay (max. up 9.5 mm height)
1 x mSATA (enabled in BIOS setting)
|
|
Expansion Interface
|
1 x Full-size PCI Express Mini Card slot (USB + PCI Express signal)
|
|
TPM
|
TPM 1.2
|
|
System Indicator
|
1 x green LED for system power-on
1 x yellow LED for HDD active
|
|
Power Input
|
12 VDC
|
|
Operating Temperature
|
-10°C to +50°C (+14°F to +122°F) (with W.T. DRAM/SSD)
|
|
Humidity
|
10% to 90%, non-condensing
|
|
Vibration Endurance
|
3 Grms with SSD (5 to 500 Hz, X, Y, Z directions)
|
|
Dimensions
|
141.6 mm (5.57") (W) x 106 mm (4.17") (D) x 54.85 mm (2.15") (H)
|
|
Weight
|
(net/gross) 0.8 kg (1.76 lb)/1.67 kg (3.68 lb)
|
|
Certifications
|
CE, FCC Class A
|
|
EOS Support
|
Win 10 IoT, Linux, AXView 2.0
|
|
| Description |
Fanless Embedded System with Intel® Core™ i5-7300U & Celeron® 3965U, 2 HDMI, 2 GbE LANs, 4 USB 3.0 and PCI Express Mini Card Slot
● Intel® Core™ i5-7300U 3.5 GHz & Celeron® 3965U 2.2 GHz
● Supports 2 COM, 2 GbE LAN and 4 USB 3.0
● One swappable 2.5" HDD drive bay
● 2 HDMI with dual-view supported
● AXView 2.0 intelligent remote monitoring software for IIoT
● Ultra-compact enclosure design
● Trusted Platform Module 1.2 (TPM) 1.2
|
