Processor CPU Intel® LGA1151 Socket 6th/7th/8th/9th Gen. Processors (TDP ≤ 65W) Chipset H310C BIOS AMI Source Code Memory Type DDR4 Socket 2 x SO-DIMM Max Size 32GB Graphics GPU Intel® HD Graphics 520/620 Graphic Engine Direct3D 2015, OpenGL 4.5, OpenCL 2.1 Interface 1 x HDMI (Max. 3840 x 2160) 1 x DP (Max. 2048 x 1536) Network Controller 2 x Realtek RTL8111H Gigabit Ethernet Interface 2 x RJ45 I/O USB 4 x USB3.0, 4 x USB2.0 Serial Port 1 x RS232 Audio 1 x 2-in-1 Headset (AUDIO-OUT&SPDIF) M.2 1 x M.2 (2230) for WiFi/BT 1 x M.2 (2242/2280) for SSD JAHC WatchDog Timer 0~255 Second Time Out Support Auto Power On Power Activated Automatically Start RTC Set Up Independently Every day, A Week as a Cycle Wake on LAN Remote Real-time Wake-up Storage M.2 1 x M.2 (2242/2280) for SSD Operation System Windows Windows 10（64-Bit） Linux Supported Power Power Type DC-IN Power Adapter 19V 4.74A Mechanical Dimensions (W x D x H) 180mm x 177mm x 36mm (7.09” x 6.97” x 1.42”) Construction Metal Mounting(Optional) VESA Mounting Kit (JZ 300) Deaktop Kit (JC 189) Color Black Environment Operating Temperature 0℃ ~ 45℃ ( 32 ℉ ~ 113 ℉ ) at 0.7m/s Air Flow Relative Humidity 95% @ 40℃ (non-condensing) Certification Certification CE, FCC
