AV600X-CH Military IP66 Mission GPU Computer
MIL-STD 810 Thermal, shock, vibration, Humidity/EMI/EMC conditions, IP66 Chassis with D38999 connectors
Key Features:
- MIL-STD 810 Thermal, shock, vibration, Humidity/EMI/EMC conditions
- IP66 Chassis with D38999 connectors
- Intel® 9th Gen. Coffee Lake (H) Xeon® E-2276ML processor
- Up to 128GB DDR4 SO-DIMM, non-ECC and ECC
- NVIDIA RTX™ A1000, 2048 CUDA® cores, 4GB GDDR6 memory
- NVMe 3.0 512GB.(MB/sec, Max.) 3,400/3,200 MB
- MIL-STD-461 18V~36V DC-Input (Options for MIL-704/1275)
- Extreme Temperature : -40°C to 55°C
- Optional with External GPU Turbo Kit
- Dimensions : 250(L) x 313.5 (W) x 100 (H) mm
The AV600X-CH is powered by Intel® 9th Gen Coffee Lake-H Xeon Processors. These processors are fabricated using Intel's cutting-edge 14 nm technology, offering up to 6 CPU cores. They provide exceptional computing performance and flexibility, making them well-suited for demanding IoT workloads. The H-series processors are particularly designed for space-constrained and purpose-built applications. They offer a variety of options for scalable performance, delivering significant improvements over the previous generation with up to 6 cores.
The AV600X-CH is distinguished by its robust design and high functionality. The system is equipped with MIL-STD Amphenol type connectors and boasts full IP66 protection, enabling it to withstand even the harshest environmental conditions. Additionally, the AV600X-CH supports an extended temperature range from -40°C to 55°C and features a MIL-STD-461 compliant 18V~36V DC-input power supply. This power supply safeguards the system against damage from voltage surges, further enhancing the reliability of its critical components and the system itself.
| brand | 7StarLake | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Specifications |
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Description | The AV600X-CH is powered by Intel® 9th Gen Coffee Lake-H Xeon Processors. These processors are fabricated using Intel's cutting-edge 14 nm technology, offering up to 6 CPU cores. They provide exceptional computing performance and flexibility, making them well-suited for demanding IoT workloads. The H-series processors are particularly designed for space-constrained and purpose-built applications. They offer a variety of options for scalable performance, delivering significant improvements over the previous generation with up to 6 cores. The AV600X-CH is distinguished by its robust design and high functionality. The system is equipped with MIL-STD Amphenol type connectors and boasts full IP66 protection, enabling it to withstand even the harshest environmental conditions. Additionally, the AV600X-CH supports an extended temperature range from -40°C to 55°C and features a MIL-STD-461 compliant 18V~36V DC-input power supply. This power supply safeguards the system against damage from voltage surges, further enhancing the reliability of its critical components and the system itself.
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
