32BDL4031D 32" Full HD

Connectivity

Video input

• Display Port1.2x1
• DVI-I x 1
• HDMI (x2)

Audio input

3.5 mm jack

Audio output

3.5mm jack

External control

• RJ45
• RS232C (in/out) 2.5 mm jack
• IR (in/out) 3.5 mm jack

Video output

• DisplayPort1.2x1
• DVI-I x1

Convenience

Screen saving functions

Pixel Shift

Tiled Matrix

Up to 15 x 15

Keyboard control

• Lockable
• Hidden

Network controllable

• RS232
• RJ45

Signal Loop Through

• IR Loopthrough
• DVI

Picture in picture

PIP

Dimensions

Bezel width

10.8 mm (T/L/R), 15.7 mm (B)

Set Width

724.8  mm

Set Height

424.3  mm

Set Depth

64.1  mm

Set Width (inch)

28.54  inch

Set Height (inch)

16.7  inch

Set Depth (inch)

2.52  inch

VESA Mount

200 x 200 mm M6

Product weight

6.15  kg

Product weight (lb)

13.55  lb

Operating conditions

Temperature range (operation)

5 ~ 40  °C

Temperature range (storage)

-10 ~ 50  °C

MTBF

50,000  hour(s)

Altitude

0 ~ 3000 m

Humidity range (operation)[RH]

10 ~ 80% (without condensation)

Humidity range (storage) [RH]

0 ~ 90% (without condensation)

Relative humidity

20 ~ 80  %

Power

Consumption (On mode)

110W( max)

Mains power

AC (100 ~ 240 V) , 2.5A

Standby power consumption

<0.5 W

Consumption (Typical)

60  W

Sound

Built-in speakers

2 x 10W RMS

Accessories

Included accessories

• AC Power Cord
• RS232 cable
• Remote Control
• Batteries for remote control
• Quick start guide

Included Accessories

• Edge Alignment Kit (1 )-2pcs
• Edge Alignment Kit (2)-1pcs
• M3 screw x 1
• RS232 daisy-chain cable
• SD card cover x 1
• Thumb Screw x8

Stand

Universal Stand-S (BM05911)(Option)

Miscellaneous

Warranty

3 year warranty
